Video Intercom KIT
-
Designed with a single call button for quick and easy communication.
-
Automatically saves messages and snapshots to the included TF card for convenient record-keeping.
-
Remote access via the Hik-Connect mobile app allows you to monitor and control your system anytime, anywhere.
-
Package Includes:
-
1 × DS-KD8003-IME1(B)/Surface Unit
-
1 × DS-KH6320-WTE1 Indoor Station
-
1 × 4-Port Standard PoE Switch
-
1 × 16 GB TF Card
-
-
Power adapter provided within the package for hassle-free setup.
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
About this item
Secure your home or villa with the Hikvision IP Video Intercom System, available at CCTV Mart. Featuring a 2MP HD camera with night vision, WDR, and digital noise reduction, the door station ensures clear video even in low-light conditions. Its single call button allows easy communication, while motion detection and image storage on the included TF card keep you informed of every visitor.
The indoor station comes with a 7-inch capacitive touch display and built-in audio for noise-free, echo-canceled conversations. With support for wired and wireless networks and Hik-Connect mobile app, you can monitor and control your system remotely. Durable, easy to install, and weather-resistant, this system delivers reliable security and smart home convenience in one compact solution.
| Category | Parameter | Details |
|---|---|---|
| System | Operating System | Embedded Linux |
| Flash | 32 MB | |
| RAM | 256 MB | |
| Video | Camera | 2MP HD camera |
| Night Vision | Low illumination IR supplement mode: 3 m | |
| Backlight Compensation | Supported | |
| Digital Noise Reduction | Supported | |
| WDR | Supported | |
| Field of View | Horizontal: 146°, Vertical: 82° | |
| Video Compression | H.264, H.265, MJPEG | |
| Motion Detection | Supported | |
| Audio | Audio Input | Built-in omnidirectional microphone |
| Audio Output | Built-in loudspeaker | |
| Audio Quality | Noise suppression and echo cancellation | |
| Audio Compression | G711U, G711A, G726, AAC_LC, AAC_LD, OPUS, G722.1 | |
| Bitrate | 64 Kbps | |
| Network | Protocol | TCP/IP, RTSP, IPv6, ONVIF |
| Wired Network | 10/100 Mbps Ethernet | |
| Device Interfaces | Network Interface | 1 × RJ45 |
| RS-485 | 1 (for Hikvision sub-module communication) | |
| Alarm Input | 4 (2 exit buttons, 2 door contacts) | |
| Debugging Port | 1 | |
| Lock Control | 2 relays (max 30 V, 2 A) | |
| Tamper Switch | 1 | |
| Power Interface | 12 VDC output (max 12 V, 500 mA) | |
| General | Power Consumption | ≤ 5 W |
| Operating Temperature | -40°C to 60°C | |
| Operating Humidity | 10% to 95% | |
| Dimensions | Device: 98 × 100 × 42 mm; Cover: 117 × 107 × 4 mm; Frame: 117 × 107 × 32.7 mm | |
| Installation | Surface mounting | |
| Protection Level | IP65 | |
| Power Supply | IEEE802.3af PoE / 12 VDC |
| ram | 16GB, 8GB |
|---|---|
| internal-storage | 256GB, 512GB |
