8-Channel 5 MP 1U H.265 AcuSense DVR
-
8-channel AcuSense DVR with AI facial recognition & perimeter protection
-
Supports 4K/8MP @ 8fps and 5MP @ 12fps recording
-
Up to 16 IP camera inputs, each up to 8MP
-
H.265 Pro+ compression for efficient video storage
-
Up to 16 facial picture libraries with backup support
-
5-signal adaptive input: HDTVI/AHD/CVI/CVBS/IP
-
HDMI output up to 4K resolution
-
Supports All-Channel Motion Detection Technology
- Estimated Delivery : Up to 4 business days
- Free Shipping & Returns : On all orders over $200
About this item
The 8-Channel 5 MP 1U H.265 AcuSense DVR (iDS-7208HUHI-M1/X) is built to deliver advanced surveillance powered by Deep Learning technology. With 8 analog channels and support for up to 16 IP cameras, this DVR ensures crystal-clear recording, smart analytics, and reliable performance. Equipped with Facial Recognition, it supports up to 16 face picture libraries, providing accurate identification and quick image searches. The AcuSense technology enables perimeter protection with human and vehicle classification, reducing false alarms and enhancing accuracy.
Enjoy seamless connectivity with 5-signal input compatibility (HDTVI, AHD, CVI, CVBS, IP) and flexible playback with up to 8-channel synchronous viewing. The H.265 Pro+ compression significantly optimizes storage without compromising image quality. Ideal for small to medium surveillance setups, this DVR offers a balance of high-end AI features, 4K HDMI output, and robust performance—perfect for professional monitoring systems.
| Category | Specification |
|---|---|
| Model number | iDS-7208HUHI-M1/X |
| Model | 8-ch 5 MP 1U H.265 AcuSense DVR |
| Main Features | 8 channels and 1 HDD 1U AcuSense DVR |
| AI Features | 4-ch Facial Recognition or 8-ch Perimeter Protection (Deep Learning) |
| AcuSearch Technology | Supported (8-channel) |
| Compression | H.265 Pro+, H.265 Pro, H.265, H.264+, H.264 |
| Encoding Ability | Up to 4K/8MP @ 8fps; 3K/5MP @ 12fps |
| IP Camera Input | Up to 16 channels (each up to 8MP) |
| Adaptive Signal Input | HDTVI/AHD/CVI/CVBS/IP |
| Facial Recognition | Up to 16 face picture libraries with HDD + flash backup |
| Face Picture Comparison | 4-channel face picture comparison alarm (HD analog camera) |
| Perimeter Protection | Human/Vehicle classification up to 8 channels |
| Facial Detection & Capture | Up to 4-channel detection and capture |
| Analog Video Input | 8-ch, BNC interface (1.0 Vp-p, 75 Ω) with coaxitron support |
| IP Video Input | 8-ch (expandable to 16-ch, 4 Mbps each) |
| HDMI Output | 4K (3840×2160)@30Hz, 2K, 1080p, 720p resolutions |
| VGA Output | 1080p/720p, simultaneous with HDMI |
| CVBS Output | 1-ch, PAL: 704×576 / NTSC: 704×480 |
| Audio Input | 1-ch (expandable to 8-ch), RCA (2.0 Vp-p, 1 KΩ) |
| Audio Output | 1-ch, RCA (Linear, 1 KΩ) |
| Two-Way Audio | Supported (via first audio input) |
| Video Resolution Support | 8MP/5MP/4MP/3MP/1080p/720p/WD1/4CIF/VGA/CIF |
| Frame Rate | Main: 8MP@8fps, 5MP@12fps, 1080p@25/30fps; Sub: WD1/4CIF/CIF@25/30fps |
| Video Bitrate | 32 Kbps – 10 Mbps |
| Decoding Capability | Up to 24-ch 1080P@30fps |
| Network Bandwidth | 256 Mbps |
| Network Interface | RJ45 10M/100M/1000M self-adaptive Ethernet |
| Remote Connections | Up to 64 |
| Supported Protocols | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF, ISUP |
| Storage | 1 SATA interface (up to 12TB HDD) |
| USB Interfaces | Front: 1×USB 2.0; Rear: 1×USB 3.0 |
| RS-485 Interface | Supported (half-duplex) |
| Alarm I/O | Optional support |
| Power Supply | 12 VDC, 2 A |
| Power Consumption | ≤ 10 W (without HDD) |
| Operating Temperature | -10°C to 55°C (14°F to 131°F) |
| Operating Humidity | 10% to 90% |
| Dimensions (W × D × H) | 319 × 240 × 48 mm (12.6 × 9.4 × 1.9 inch) |
| Weight | ≤ 2 kg (4.4 lb) |
| Weight | 0.300 kg |
|---|---|
| color | Black, Blue, Orange |
